自動中空押出ブロー成形機FS-40PDDL-75

分類: 自動中空押出ブロー成形機
国: 台湾
電話番号: 886-4-22765071
ファックス: 886-4-22765070
連絡先: Ms. Huang
お問い合わせ

<• 多層共押出式中空吹氣成型機,以單模架或雙模架機型,搭配單模頭至多模頭之多層共押出模頭設計;適合吹塑由二層至六層之塑膠容器,例如農藥瓶、蕃茄醬瓶和化妝品瓶等。多層共押出技術採用鍑鑫特殊設計之模頭,讓不同屬性之塑料結合。 >
•異なる技術の組み合わせは、そのような明るい外表面層として共押出プラスチックであってもよく、内側層は、所望の特性及び性能を達成するために、内側と外側のプラスチックに接着バリア層、及び接着層です。
•高度な技術フー新リードの多層共押出アプリケーション。

EXPOSITION OF FULL SHINE'S MACHINE MODEL
  SCREW DIAMETER(M/M) MACHINE SERIES MOLD HEAD(DIE HEAD) MOLD STATION PRODUCT TYPE
FS- 40 (H) Horizontal (S) Single Mold Head (S) Single Mold Station (O) Original
45 (P) Parallel (D) Double Mold Heads (D) Double Mold Stations (C) Two Colors
55 (O) Standard / Oblique (T) Three Mold Heads   (D) Two Layers
65 (A) Pneumatic (F) Four Mold Heads   (T) Three Layers
75 (L) Frontal (E) Eight Mold Heads   (F) Four Layers
80 (I) Lateral     (L) Six Layers
90       (V) View Stripe
100       (P) PC baby bottle
Example
FS- 65 P D S D



Model FS-40 PSSD FS-45 PSSD FS-55 PSSD FS-65 PSSD FS-75 PSSD FS-55 PSSC FS-65 PSSC FS-75 PSSC
Style Double/single die head/single die holder Double color/single head single mold frame
1 Use plastic   PE PE PE PE PE PE PE PE
2 Screw diameter m/m 40/25 45/25 55/25 65/25 75/25 55/55 65/65 75/75
3 Screw ratio L/D 24/1 24/1 24/1 24/1 24/1 24/1 24/1 24/1
4 Screw speed r.p.m. 20-66 15-61 15-60 15-60 15-58 15-60 15-60 15-58
5 Inverter motor HP 5/2 7.5/2 10/2 15/2 25/2 10/10 15/15 25/25
6 Pump drive horsepower HP 5 7.5 10 10 15 10 10 15
7 Air compressor with horsepower HP 5 5 7.5 7.5 10 7.5 7.5 10
8 air pressure Kg/cm2 4-6 4-6 5-7 5-7 5-7 5-7 5-7 5-7
9 Clamping pressure Ton 2.8 3.9 4.4 6.9 10 4.4 6.9 10
10 Fuel tank capacity Gallon 38 55 60 80 120 60 80 120
11 Heating points ZONE 6 6 6 7 7 6 6 7
12 Heating capacity KW 9.5 12 15 19.5 22 19 24.5 26
13 Total power KW 19 25 32 40.5 44 43 56 77
14 Extrusion amount Kg/hr 15 24 42 55 75 42 55 75
15 Empty cycle per hour time/hr 1285 1030 880 720 650 880 720 600
16 Product capacity c.c./L 15-500 60-1000 150-2500 1L-5L 1L-10L 150-2500 1L-5L 1L-10L
17 product weight g. 5-40 10-100 20-170 40-280 80-500 20-170 40-280 80-500
18 Maximum and minimum product diameter m/m 10-75 20-100 30-140 50-200 80-260 30-140 50-200 80-260
19 Die mouth diameter m/m 50 56 80 150 200 80 150 200
20 Mold center distance m/m * * * * * * * *
21 Open and close mold limit m/m 50-320 50-410 140-540 160-670 50-410 140-540 160-670 160-670
22 Die length m/m 146-266 155-290 160-380 223-426 155-290 160-380 223-426 240-460
23 Die width m/m 300 320 360 430 320 360 430 430
24 Machine net weight Kg 3300 3800 4700 7600 3800 4700 7600 7300
25 Machine size m 2.6*1.85*2.7 3*1.9*2.8 3.1*2*2.8 3.6*1.6*3.1 4.2*1.7*3.2 3.1*2*2.8 3.6*1.6*3.1 4.2*1.7*3.2

PHOTOS

Top view side of co-extrusion 2 layers blow molding machine

PHOTOS

2 layers co extrusion bottles with view stripe line

PHOTOS

Machine photo co-extrusion 2 layers blow molding machine

PHOTOS

2 layers co-extrusion double die head

PHOTOS

Blow pin unit

PHOTOS

Barrel and screw set with fans

PHOTOS

2 layers co-extrusion double die head

PHOTOS

Top view side of co-extrusion 2 layers blow molding machine

PHOTOS

3 layers co-extrusion double die head

PHOTOS

3 layers co-extrusion double die head with hot cutter
