フォースホッパー供給プラスチックリサイクルマシン(Hシリーズ)

分類: プラスチックリサイクル造粒機
国: 台湾
電話番号: 886-4-2630-1621
ファックス: 886-4-2630-1716
連絡先: Peter
お問い合わせ

Economically Selection

A valuable selection for clean materials, without pre-heating section for feeding device, this reduces the power consumption. The axle made by special steel with heat treatment. More tenacity and allows the materials to be fed sequence stably and also anti-bridging.

Better Flexibility

Genius recycling specialist team provides customized recycling systems, flexible options from sorting, feeding, degassing, filtration, to storage and packing systems. According to the clients’ needs presenting a smart and reliable plant.

Cost Saving

Energy cost save up to 10%. Labor cost is reduces as only 1~2 operators are needed to operate the whole plant.

モデル H-DFC-85 H-DFC-100 H-DFC-125 H-DFC-150 H-DFC-175
H-SPR-85 H-SPR-100 H-SPR-125 H-SPR-150 H-SPR-175
強制送りモーター 3馬力 5馬力 7 1/2馬力 7 1/2馬力 7 1/2馬力
押出能力 150~250kg/時 250~350kg/時 400~550kg/時 550~700kg/時 750~1000kg/時
ねじ径 Φ85mm Φ100mm Φ125mm Φ150mm Φ175mm
メインモーター 75馬力 125馬力 150HP 200HP 300HP
油圧式スクリーンチェンジャーモーター 3馬力 3馬力 5馬力 7 1/2馬力 10馬力
振動スクリーナーモーター 1/4HP×2本 1/4HP×2本 1/4HP×2本 1/4HP×2本 1/2HP×2本
振動スクリーナーブロワーモーター 3馬力 7 1/2馬力 7 1/2馬力 10HP 10HP
サイロ容量 600L 600L 800L 800L 1000L
  • スクリューとバレルが両方とも輸入品で、特殊な処理がされて、磨耗に強くて、使用寿命もより長くなります。
  • シングル押出機は、きれいな対象物に適用:例えば、成型した切りくず、端材。ボトルの破片、シート状の物、或いは粉砕後の塊り。
  • 歯車箱の中身が精密研磨された歯車なので、回転時の騒音が小さくて、安定に動いています。
ホットダイフェースカッティング
ダイフェスカットはの手作業工数のコストが削減でき。
粒状切断用のカッターは自由軸の設計で、自動的に軸芯を調整できます。粉塵の生成もありません。

ホットダイフェースカッティング切断した粒状の大きさが同じ、再投入の生産ラインにも適用。


ストランド状にしてから粒状に切断
主に高粘度の材料に適用。
ストランド状になってから、一旦、冷却水水槽で冷やして、粒状切断機でペレットにします。

水中での造粒
高粘度の材料に対して設計した粒状切断法。
粒状切断と冷却を同時進行。

PET, PP, PS, PE, ABS, HIPS and more. Suitable for rigid materials, including crushed bottles, crushed industrial waste, and injection materials



Bottles Chemical Drums Industrial Waste
Injection Gate Runner Plastic Automotive Parts Parts / ABS Recycling WEEE Waste Electrical Equipment
