分類: プロダクト
型番 | 国際サイズ | 理論的な注入量 | 締付力 | タイバー間のスペース | 型開きストローク |
CX-60 | 600H-167 | 97 | 60 | 330x330 | 320 |
CX-100 | 1000H-387 | 226 | 100 | 380x380 | 370 |
CX-130 | 1300H-517 | 318 | 130 | 430x430 | 410 |
CX-160 | 1600H-764 | 442 | 160 | 500x500 | 490 |
CX-200 | 2000H-1078 | 594 | 200 | 560x560 | 550 |
CX-250 | 2500H-1400 | 778 | 250 | 610x610 | 600 |
CX-300 | 3000H-1727 | 995 | 300 | 680x680 | 660 |
CX-350 | 3500H-2101 | 1251 | 350 | 730x730 | 710 |
CX-450 | 4500H-3079 | 1885 | 450 | 810x810 | 780 |
CX-550 | 5500H-4316 | 2704 | 550 | 880x880 | 860 |
CX-700 | 7000H-5437 | 3261 | 700 | 960x960 | 950 |
CX-950 | 9500H-8472 | 4752 | 950 | 1160x1160 | 1250 |
CX-1250 | 12500H-12672 | 7433 | 1250 | 1360x1360 | 1500 |
CX-1600 | 16000H-16810 | 11486 | 1600 | 1560x1460 | 1700 |
5点高速トグルレバーデザイン
5ポイント高速垂直トグルの最適化されたデザイン。トグル倍率とクランプストロークの開口ストロークに対する比率をアップグレードし、ドライサイクルを30%以上削減しました。
プラテンサイズとタイバーのクリアランスが拡張され、射出成形金型の生産が増加します。
STRUCTURAL REINFORCED PLATENS DESIGN
The movable platen has a box-shaped design with a T slot and a tapped mounting layout; the thickness and rigidity of the platen are both strengthened to minimize its deformation. A self-lubricated compound plate is supported at the bottom to reduce the friction of the plate with the steel tape. The layout of the platen mounting follows Euromap standards. Optional features such as the installation of a proportional valve for positional control or an ejector on the fly are also available.
