三層インテリジェント全電動ブロー成形機

分類: 連続押出ブロー成形機
Applications: 農業 ジェリカン
国:
電話番号: 886-6-2532157
ファックス: 886-6-2533079
連絡先: Susan Wei
お問い合わせ
  • Energy Saving
    Power consumption 40~50%↓
    Production output 20~25%↑



  • ECO
    No hydraulic oil, no pollution,
    Noise level 20dB reduced.



  • Industry 4.0
    Smart manufacturing, with SCADA system.
  • Low energy consumption, less carbon footprint, no pollution, less maintenance cost 25% - 30% less energy can be saved by All Electric machine compared to traditional hydraulic one.
  • Reduce, Reuse, Recycle in Plastic
  • Capable to process more recycled grade or PCR in the middle layer of a 3 layer canister. 30% weight reduction can be achieved without compromising the quality from the drop test and stacking stability with an improved design on the shape. With 3 layer structure the use of master batch can be saves around 60-80%. The total saving of plastic in a year is tremendous. In addition, when less plastic being used per canister, with less heat, fast cooling cycle can increase the production rate.
  • Industry 4.0 Smart Manufacturing control system All production data can be collected and recorded for analysis to improve the production control in many ways:
    * Plastic consumption in virgin grade, regrind grade, master batch
    * Energy consumption data in hour/month/year, Processing condition with alarm signals Preventive maintenance instructions to keep machine always at high working efficiency.
    * Entire system in use is digital communication protocol to deliver accurate readings, also by Oracle MySQL with no size limitation and use Client/Server version can link to 5 users remote at same time.

Machine Model

FK/EHB-55G/100G/55GT20SD

Extruders

55/100/55mm, L/D=30:1

Main drive

40/125/40 HP

Max extrusion output

90 / 320 / 90 kg/hr

Product capacity

20L jerrycan

Product weight

850 g

Production rate

257 BPH (cycle time: 28 sec.)
