UXシリーズ-30/60/150

MODEL

UX-30

UX-60

UX-150

ITEM

UX-30/UXF-30

UX-60/UXF-60

U-150/UXF-150/UXF-150G

Molding Machine Size (ton)

10-30

50-90

80-150

A. Full Length

480

B. Full Width

540

620

740

C. Height of Main Arm

1150

1250

1350

D. Height of Sub Arm

X

X/1350

E. Max. Radius of Products Handled

292/357

292/357

342/407/407(342)

F. Min. Distance b/w the Arms

X

X/60

G. Standby Position of Main Arm

0-235/0-170

0-235/0-170

0-185/0-120/0-120

H. Standby Position of Sub Arm

X

0-185

I.  Distance b/w Main arm and Base

X

J. Distance b/w Sub Arm and Base

X

K. Vertical Stroke of Main Arm

350

450

550

L. Vertical Stroke of Sub Arm

X

X/X/550

M. Min. Distance from Sub Arm to Base

X

X/X/60

N. Min. Distance from Main Arm to Base

62

60/60/150

P. Max. Demolding Stroke

190

270

390

Q. Controller Width

250

R. Controller Height

935

S. X Axis Width

232

T. Y Axis Width

900

U. Z Axis Height

500

V. Base Width

125
